UHP (Ultra High Purity) Grade Hydrogen, Size 150 High Pressure Aluminum, CGA 350 UHP (Ultra High Purity) Grade Hydrogen, Size 150 High Pressure Aluminum, CGA 350

UHP (Ultra High Purity) Grade Hydrogen, Size 150 High Pressure Aluminum, CGA 350

By
Airgas
Datasheet
SDS

Airgas Part #:HY UHP15A

Manufacturer Part #:UHP15A


Enter Delivery Zip Code or Log In

About this product



GAS INFO
CYLINDER DETAILS

Specifications


GAS GRADE % PURITY O2 H2O THC CO CO2 AR N2
Ultra High Purity (UHP) 99.999 1 2 0.5 1(2) 1(2) 0 5

*Concentrations given are ppm by volume unless otherwise specified.


Product Attributes

CGA Connection

• CGA 350

Gas Grade

• UHP
Features

  • Airgas operates its own dedicated blending facilities as well as maintains a national network of blending technology to ensure accurate, consistent production.
  • Individual or Batch Certificate of Analysis available upon request.

Applications

  • Hydrogen has become an ideal alternative energy source because of its tendency to produce lower unwanted emissions.
  • Typically mixed with argon, hydrogen is used for welding and cutting stainless steel.
  • Hydrogen is used in chemical synthesis to produce ammonia, methanol and other products.
  • In refineries hydrogen is used to process crude oil into refined oils, such as gasoline and diesel, and to remove contaminants.
  • Hydrogen is also essential in chemical processing such as creating sulfuric and hydrochloric acids.
  • Hydrogen is sometimes used instead of helium as the carrier gas in gas chromatography (GC).
  • Hydrogen gas is essential for rocket propulsion as well as powering and maintaining spacecrafts.

Safety

  • Always use in accordance with the Safety Data Sheet (SDS)
  • Cylinder must be stored and used in an upright, secured position in a well-ventilated or monitored area.
  • Always follow local fire code requirements when storing gas cylinders.
  • Major hazards: Fire (extremely flammable)

Specifications

Sizes may vary by location. Contact your local Airgas representative or local branch location for availability in your area.


DIMENSIONS

Size
150 Aluminum HP
DOT Specification
3AL - 2015
O.D.
8" - 20 cm
Length
48" - 122 cm
Weight
48 lbs - 22 kg
Matheson Trigas
1R
MG
150AL
Scott
AL
